High Speed Wrapper

Brief Introduction：
High Speed wrappers are ideal for higher-volume packaging applications that wrap 25 or more loads per hour. Automatic pallet wrappers attach the machine stretch wrap to the pallet, wrap the load, cut the stretch film, and secure the tail to the load, requiring minimal to no operator interaction.
Applied To: Any material packed by Pallet, bags, cartons, cases & bundle.

Whatsapp：+86 15371056062

E-mail：sales@dostar-packing.com

Detail

GENERAL INTRODUTION

High speed arm type wrapping machine have two film carriage and efficiency of work is much faster, angle bead device can be optional and can increase the function of top pressing and film. Suitable for large volume and weight goods. Double head rocker increases a cantilever on the basis of single arm winding, and the working efficiency has been greatly improved. With the same winding requirements, the time is almost half saved, which is a rare winding tool for many enterprises with high requirements of assembly line operation

WORKING PARAMETERS

DESCRIPTION	PARAMETERS
Wrapping Speed	0-60 RPM
Wrapping Capacity	30-60 loads/hour
Maximum Pallet Size	1100*1200 Customizable
Maximum Pallet Carriage Height	2200mm Customizable
Load Weight Max.	2200KG Customizable
Power Supply	380V 50/60HZ
Power	7.5Kw
Film Tension	Adjustable
Film Pre-stretch	125~400%
Air Consumption	0.4-0.6MPa 1000ml/min
Machine Size	L4300xW2320xH3530mm
Machine Weight	2500mm
HIGH SPEED ARM usually works with the whole packaging line and the control system can be integrated to the main control system. Also, we welcome oversized wrapping machine OEM.
